Description
Fluid dynamic bearing (FDB)FDB (Fluid Dynamic Bearing) structure generates high pressure oil layer on micro channel's intersecting point, which prevents friction between the fan's shaft and bearing, thus resulting in maximum fan lifespan (150,000hrs) with minimum noise.
Shark fin blade designOptimized for maximum airflow, Shark`s Fin blade greatly reduces the turbulence caused by fan rotation, thus decreasing the noise and vibration while increasing the airflow.
Minimized noise and vibrationMinimized noise and vibration through lowest rpm.
Silicone pin providedSilicone pin absorbs the vibration between the fan and the case allowing a quiet work environment.
| Performance |
| Suitable for: | Computer case |
| Type: | Fan |
| Supported processor sockets: | Not supported |
| Fan diameter: | 12 cm |
| Compatible processor series: | Not supported |
| Rotational speed (max): | 1200 RPM |
| Noise level (low speed): | 20 dB |
| Noise level (high speed): | 23 dB |
| Mean time between failures (MTBF): | 150000 h |
| Bearing type: | Fluid Dynamic Bearing (FDB) |
| Design |
| Number of fans: | 1 fan(s) |
| Colour of product: | Black, Transparent |
| Material: | Plastic |
| Power |
| Voltage: | 12 V |
| Weight & dimensions |
| Height: | 25 mm |
| Width: | 120 mm |
| Depth: | 120 mm |
| Weight: | 100 g |
