Description
Technical data
Case form factor: ATX Mid- Tower
Dimensions: 473(D) x 245(W) x 496(H)mm
Weight: 9.6kg
Materials: Plastic, steel, tempered glass
Motherboard support: E-ATX / ATX / M-ATX / Mini-ITX
Maximum VGA length: 390mm
Maximum CPU cooler height: 185mm
Maximum PSU length: 270mm
PCI expansion slots:
7 pcs
3 pcs (Vertical 65mm)
Drive bays:
3.5” : 2 x 2.5" SSD/HDD or 2 x 3.5" HDD
2.5” : 3 x 2.5” SSD/HDD or 2 x 3.5” HDD
Fan support:
Front: 3 x 120mm / 3 x 140mm / 2 x 200mm(H: 25mm)
Top: 3 x 120mm / 2 x 140mm
Rear: 1 x 120mm / 1 x 140mm
Fan(s) included:
Front: 3 x 140mm (ARGB)
Rear: 1 x 140mm (ARGB)
Radiator support:
Front: 120mm / 140mm / 240mm / 280mm / 360mm
Top: 120mm / 140mm / 240mm / 280mm / 360mm
Rear: 120mm / 140mm
I/O Ports: USB3.0 x 2, USB2.0 x 2, USB 3.1 Gen2 Type-C x 1, Mic, HD Audio, LED button, Reset button, Power button with HDD LED
